Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in making in manufacturing construction equipment. Machines like aerial lifts, manlifts and boom lifts. These machines are designed to facilitate access to hard to reach areas, roofs and buildings, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt moves only in one direction and includes handholds or platforms or steps that are attached to the unit to be able to move workers from each floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This model offers a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height measures at 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
